Data sheet Pressure transducers DMU 01 standard version
AFRISO Data sheet Pressure transducers DMU 01 standard version

Benefits

  • Proven ceramic technology
  • No mechanical ageing of the measuring cell
  • No transmission liquid
  • Versions for relative pressure and absolute pressure
  • Small temperature error

Application

For electronic pressure measurement in industrial applications (such as hydraulic and pneumatic applications as well as mechanical and plant engineering).

Versions

Type Connection Measuring range Part no. Remember
DMU 01 G½B EN 837-1/7.3 -1/0 bar 31114
DMU 01 G½B EN 837-1/7.3 -1/+1.5 bar 31616
DMU 01 G½B EN 837-1/7.3 -1/+3 bar 31617
DMU 01 G½B EN 837-1/7.3 -1/+5 bar 31618
DMU 01 G½B EN 837-1/7.3 0/1 bar 31115
DMU 01 G½B EN 837-1/7.3 0/1.6 bar 31116
DMU 01 G½B EN 837-1/7.3 0/2.5 bar 31117
DMU 01 G½B EN 837-1/7.3 0/4 bar 31118
DMU 01 G½B EN 837-1/7.3 0/6 bar 31119
DMU 01 G½B EN 837-1/7.3 0/10 bar 31120
DMU 01 G½B EN 837-1/7.3 0/16 bar 31121
DMU 01 G½B EN 837-1/7.3 0/25 bar 31122
DMU 01 G½B EN 837-1/7.3 0/40 bar 31123
DMU 01 G½B EN 837-1/7.3 0/60 bar 31124
DMU 01 G½B EN 837-1/7.3 0/100 bar 31125
DMU 01 G½B EN 837-1/7.3 0/160 bar 31126
DMU 01 G½B EN 837-1/7.3 0/200 bar 31878
DMU 01 G½B EN 837-1/7.3 0/250 bar 31127
DMU 01 G½B EN 837-1/7.3 0/400 bar 31128
DMU 01 VM G½B DIN 3852 type E -1/0 bar 31619
DMU 01 VM G½B DIN 3852 type E -1/+1.5 bar 31620
DMU 01 VM G½B DIN 3852 type E -1/+3 bar 31621
DMU 01 VM G½B DIN 3852 type E -1/+5 bar 31622
DMU 01 VM G½B DIN 3852 type E 0/1 bar 31623
DMU 01 VM G½B DIN 3852 type E 0/1.6 bar 31624
DMU 01 VM G½B DIN 3852 type E 0/2.5 bar 31625
DMU 01 VM G½B DIN 3852 type E 0/4 bar 31626
DMU 01 VM G½B DIN 3852 type E 0/6 bar 31627
DMU 01 VM G½B DIN 3852 type E 0/10 bar 31628
DMU 01 VM G½B DIN 3852 type E 0/16 bar 31629
DMU 01 VM G½B DIN 3852 type E 0/25 bar 31630

Blue part no. = in-stock items

Description Format Language Download / Link
Data sheet Pressure transducers DMU 01 standard version Data sheet PDF
AFRISO Data sheet Pressure transducers DMU 01 standard version
Pressure transmitters / screw-in probes DMU 01, DMU 01 K, DMU 03, DMU 03 HD, DMU 04, DMU 05P, DMU 07, DMU 07 FG Operating instructions PDF
AFRISO Pressure transmitters / screw-in probes DMU 01, DMU 01 K, DMU 03, DMU 03 HD, DMU 04, DMU 05P, DMU 07, DMU 07 FG
Electronic pressure measurement - pressure transducers DMU series Product range industrial technology PDF
AFRISO Electronic pressure measurement - pressure transducers DMU series
Enquiry pressure transducers DMU Checklists PDF
AFRISO Enquiry pressure transducers DMU
Pressure transducers DMU 01, DMU 03, DMU 04, DMU 05, DMU 08, DMU 08T Declaration of Conformity PDF
AFRISO Pressure transducers DMU 01, DMU 03, DMU 04, DMU 05, DMU 08, DMU 08T
NA Pressure transducers DMU 01 standard version Options PDF
AFRISO NA Pressure transducers DMU 01 standard version
Pressure transducers convert physical pressure into an electrical signal proportional to the pressure. DMU 01 is equipped with a piezo-resistive thick-film ceramic measuring cell.
Measuring accuracy
Deviation from the characteristic curve according to IEC 60770 – limit point calibration (non-linearity, hysteresis, repeatability)
-1/0 bar < ± 1 % FSO
< ± 0.5 % FSO
Measuring range
See ordering table
Overpressure safety
< 250 bar:
At least 2 x FS
250 bar:
400 bar
400 bar:
650 bar
Burst pressure
< 400 bar:
At least 3 x FS
400 bar:
1000 bar
Operating temperature range
Medium:
-25/+125 °C
Ambient:
-25/+85 °C
Storage:
-40/+85 °C
Temperature error band
≤ ± 0.3 % FSO/10 K In compensated range -25/+85 °C
Dynamic characteristics
Response time:
≤ 10 ms
Process connection
G½B EN 837-1/7.3
G½B DIN 3852 type E with protruding diaphragm
Material
Housing:
Stainless steel 304
Pressure connection:
Stainless steel 304
Diaphragm:
Ceramic (Al2O3 96 %)
Seal:
FKM (Viton)
Supply voltage
DC 8 – 32 V
Output signal
2-wire, 4–20 mA
Load
R<sub>Max</sub> = [(UB – UB<sub>Min</sub>)/0.02 A] Ω
Current input
< 25 mA
Electrical protection
Short circuit proof and protected against reverse polarity
Electrical connection
Connector and junction box as per ISO 4400 (DIN 43650-A, EN 175301-803)
Degree of protection
IP 65 (EN 60529)
CE conformity
EMC Directive 2014/30/EU
RoHS Directive 2011/65/EU
Pressure Equipment Directive 2014/68/EU

Options

  • Other connection threads
  • Fixed cable connection
  • Other output signals
  • SIL 2 (IEC 61508/61511) 2-wire, for DMU 01 VM
DMU 01 - connection G½B EN 837
AFRISO
DMU 01 - connection G½B EN 837
AFRISO
Dimensions (in mm)
DMU 01 VM with connection G½B DIN 3852 type E with protruding diaphragm
AFRISO
DMU 01 VM with connection G½B DIN 3852 type E with protruding diaphragm
AFRISO
Dimensions (in mm)
  1. Flat gasket FKM (Viton)
wiring diagram
AFRISO
wiring diagram
AFRISO
3-wire 0-10 V
wiring diagram
AFRISO
wiring diagram
AFRISO
2-wire, 4-20 mA
